Specification

Value

Motor

4 × (3Hp – 3 phase – 2P)

Rotating speed of drill spindle

2800 rpm

Displacement of vertical and horizontal drill bits

80 mm

Angle of rotation

360°

Cylinder for clamping the workpiece

04 pcs

Working distance in the horizontal direction

300 – 2400 mm

Drill diameter

Ø1.5 – Ø13 mm

Working pressure of pneumatic cylinder

4 – 6 kgf/cm²

Machine dimensions (L×W×H)

3000 × 1300 × 1600 mm

Machine net weight

1500 kg

Timber species

Softwood / Hardwood

Operating voltage

380V ± 5%, 50Hz
